area.plot {ade4}R Documentation

Graphical Display of Areas

Description

'area' is a data frame with three variables.
The first variable is a factor defining the polygons.
The second and third variables are the xy coordinates of the polygon vertices in the order where they are found.

area.plot : grey levels areas mapping

poly2area takes an object of class 'polylist' (maptools package) and returns a data frame of type area.
area2poly takes an object of type 'area' and returns a list of class 'polylist'
area2link takes an object of type 'area' and returns a proximity matrix which terms are given by the length of the frontier between two polygons.
area.util.contour,area.util.xy and area.util.class are three utility functions.

Usage

area.plot(x, center = NULL, values = NULL, graph = NULL, lwdgraph = 2,
nclasslegend = 8, clegend = 0.75, sub = "", csub = 1,
possub = "topleft", cpoint = 0, label = NULL, clabel = 0, ...)

area2poly(area)
poly2area(polys)
area2link(area)
area.util.contour(area)
area.util.xy(area)

Arguments

x a data frame with three variables
center a matrix with the same row number as x and two columns, the coordinates of polygone centers. If NULL, it is computed with area.util.xy
values if not NULL, a vector which values will be mapped to grey levels. The values must be in the same order as the values in unique(x.area[,1])
graph if not NULL, graph is a neighbouring graph (object of class "neig") between polygons
lwdgraph a line width to draw the neighbouring graph
nclasslegend if value not NULL, a number of classes for the legend
clegend if not NULL, a character size for the legend, used with par("cex")*clegend
sub a string of characters to be inserted as sub-title
csub a character size for the sub-titles, used with par("cex")*csub
possub a string of characters indicating the sub-titles position ("topleft", "topright", "bottomleft", "bottomright")
cpoint if positive, a character size for drawing the polygons vertices (check up), used with par("cex")*cpoint
label if not NULL, by default the levels of the factor that define the polygons are used as labels. To change this value, use label. These labels must be in the same order than unique(x.area[,1])
clabel if not NULL, a character size for the polygon labels,
used with par("cex")*clabel
polys a list belonging to the 'polylist' class in the spdep package
area a data frame of class 'area'
... further arguments passed to or from other methods

Value

poly2area returns a data frame 'factor,x,y'.
area2poly returns a list of class polylist.

Author(s)

Daniel Chessel

Examples

data(elec88)
par(mfrow = c(2,2))
area.plot(elec88$area, cpoint = 1)
area.plot(elec88$area, lab = elec88$lab$dep, clab = 0.75)
area.plot(elec88$area, clab = 0.75)
# elec88$neig <- neig(area = elec88$area)
area.plot(elec88$area, graph = elec88$neig,
sub = "Neighbourhood graph", possub = "topright")
par(mfrow = c(1,1))

## Not run:
par(mfrow = c(3,3))
for (i in 1:9) {
    x <- elec88$tab[,i]
    area.plot(elec88$area, val=x,
    sub = names(elec88$tab)[i], csub = 3, cleg = 1.5)
}

par(mfrow = c(3,3))
for (i in 1:9) {
    x <- elec88$tab[,i]
    s.value(elec88$xy, elec88$tab[,i], contour = elec88$contour,
    meth = "greylevel", sub = names(elec88$tab)[i], csub = 3,
    cleg = 1.5, incl = FALSE)
}

data(irishdata)
par(mfrow = c(2,2))
w <- area.util.contour(irishdata$area)
xy <- area.util.xy(irishdata$area)
area.plot(irishdata$area, cpoint = 1)
apply(w, 1, function(x) segments(x[1],x[2],x[3],x[4], lwd = 3))
area.plot(irishdata$area, clabel = 1)
s.label(xy, area = irishdata$area, incl = FALSE, clab = 0,
cpoi = 3, addax = FALSE, contour = w)
s.label(xy, area = irishdata$area, incl = FALSE,
addax = FALSE, contour = w)
if (require(maptools, quiet = TRUE) & require(spdep, quiet = TRUE)) {
    data(columbus)
    par(mfrow = c(2,2))
    plot(col.gal.nb, coords, pch = 20, cex = 2)
    col.gal.neig <- nb2neig(col.gal.nb)
    s.label(data.frame(coords), neig = col.gal.neig,
    inc = FALSE, addax = FALSE, clab = 0, cneig = 1, cpo = 2)
     maptools:::plot.polylist(polys,bbs)
    area.plot(poly2area(polys))

    # 1
    crime.f <- as.ordered(cut(columbus$CRIME,
    breaks = quantile(columbus$CRIME, probs = seq(0,1,0.2)),
    include.lowest = TRUE))
    colours <- c("salmon1", "salmon2", "red3", "brown", "black")
    plot(bbs[,1], bbs[,4], xlab = "", ylab = "", asp = 1, type = "n",
    xlim = range(c(bbs[,1], bbs[,3])), ylim = range(c(bbs[,2],
     bbs[,4])))
    for (i in 1:length(polys))
    polygon(polys[[i]], col = colours[unclass(crime.f[i])])
    legend(x = c(6, 7.75), y = c(13.5, 15), legend = levels(crime.f),
    fill = colours, cex = 0.7)
    title(sub = paste("Columbus OH: residential burglaries and ",
    "vehicle\nthefts", "per thousand households, 1980"))

    # 2
    area1 <- poly2area(polys)
    w <- area.util.contour(area1)
    wxy <- area.util.xy(area1)
    area.plot(area1, values = columbus$CRIME, sub = paste("Columbus ",
    "OH: residential burglaries and vehicle\nthefts",
    "per thousand households, 1980"))
    apply(w, 1, function(x) segments(x[1], x[2], x[3], x[4], lwd = 2))

    # 3
    data(elec88)
    fr.area <- elec88$area
    fr.xy <- area.util.xy(fr.area)
    fr.neig <- elec88$neig # neig(area = fr.area)

    # 4
    fr.poly <- area2poly(fr.area)
    fr.nb <- neig2nb(fr.neig)
    maptools:::plot.polylist(fr.poly, attr(fr.poly, "region.rect"), border = "grey")
    plot(fr.nb, fr.xy, add = TRUE)
    s.label(fr.xy, clab = 0, area = fr.area, neig = fr.neig,
    cneig = 1, cpo = 2, inc = FALSE, addax = FALSE)
par(mfrow=c(1,1))
}
## End(Not run)

data(irishdata)
w <- irishdata$area[c(42:53,18:25),]
w
w$poly <- as.factor(as.character(w$poly))
area.plot(w, clab = 2)

points(68, 59, pch = 20, col = "red", cex = 3)
points(68, 35, pch = 20, col = "red", cex = 3)
points(45, 12, pch = 20, col = "red", cex = 3)
sqrt((59-35)^2)+sqrt((68-45)^2+(35-12)^2)
area2link(w)

Worked out examples


> library(ade4)
> ### Name: area.plot
> ### Title: Graphical Display of Areas
> ### Aliases: area.plot poly2area area2poly area2link area.util.contour
> ###   area.util.xy area.util.class
> ### Keywords: hplot
>
> ### ** Examples
>
> data(elec88)
> par(mfrow = c(2,2))
> area.plot(elec88$area, cpoint = 1)
> area.plot(elec88$area, lab = elec88$lab$dep, clab = 0.75)
> area.plot(elec88$area, clab = 0.75)
> # elec88$neig <- neig(area = elec88$area)
> area.plot(elec88$area, graph = elec88$neig,
+ sub = "Neighbourhood graph", possub = "topright")
> par(mfrow = c(1,1))
>
> par(mfrow = c(3,3))
> for (i in 1:9) {
+     x <- elec88$tab[,i]
+     area.plot(elec88$area, val=x,
+     sub = names(elec88$tab)[i], csub = 3, cleg = 1.5)
+ }
>
> par(mfrow = c(3,3))
> for (i in 1:9) {
+     x <- elec88$tab[,i]
+     s.value(elec88$xy, elec88$tab[,i], contour = elec88$contour,
+     meth = "greylevel", sub = names(elec88$tab)[i], csub = 3,
+     cleg = 1.5, incl = FALSE)
+ }
>
> data(irishdata)
> par(mfrow = c(2,2))
> w <- area.util.contour(irishdata$area)
> xy <- area.util.xy(irishdata$area)
> area.plot(irishdata$area, cpoint = 1)
> apply(w, 1, function(x) segments(x[1],x[2],x[3],x[4], lwd = 3))
NULL
> area.plot(irishdata$area, clabel = 1)
> s.label(xy, area = irishdata$area, incl = FALSE, clab = 0,
+ cpoi = 3, addax = FALSE, contour = w)
> s.label(xy, area = irishdata$area, incl = FALSE,
+ addax = FALSE, contour = w)
> if (require(maptools, quiet = TRUE) & require(spdep, quiet = TRUE)) {
+     data(columbus)
+     par(mfrow = c(2,2))
+     plot(col.gal.nb, coords, pch = 20, cex = 2)
+     col.gal.neig <- nb2neig(col.gal.nb)
+     s.label(data.frame(coords), neig = col.gal.neig,
+     inc = FALSE, addax = FALSE, clab = 0, cneig = 1, cpo = 2)
+      maptools:::plot.polylist(polys,bbs)
+     area.plot(poly2area(polys))
+
+     # 1
+     crime.f <- as.ordered(cut(columbus$CRIME,
+     breaks = quantile(columbus$CRIME, probs = seq(0,1,0.2)),
+     include.lowest = TRUE))
+     colours <- c("salmon1", "salmon2", "red3", "brown", "black")
+     plot(bbs[,1], bbs[,4], xlab = "", ylab = "", asp = 1, type = "n",
+     xlim = range(c(bbs[,1], bbs[,3])), ylim = range(c(bbs[,2],
+      bbs[,4])))
+     for (i in 1:length(polys))
+     polygon(polys[[i]], col = colours[unclass(crime.f[i])])
+     legend(x = c(6, 7.75), y = c(13.5, 15), legend = levels(crime.f),
+     fill = colours, cex = 0.7)
+     title(sub = paste("Columbus OH: residential burglaries and ",
+     "vehicle\nthefts", "per thousand households, 1980"))
+
+     # 2
+     area1 <- poly2area(polys)
+     w <- area.util.contour(area1)
+     wxy <- area.util.xy(area1)
+     area.plot(area1, values = columbus$CRIME, sub = paste("Columbus ",
+     "OH: residential burglaries and vehicle\nthefts",
+     "per thousand households, 1980"))
+     apply(w, 1, function(x) segments(x[1], x[2], x[3], x[4], lwd = 2))
+
+     # 3
+     data(elec88)
+     fr.area <- elec88$area
+     fr.xy <- area.util.xy(fr.area)
+     fr.neig <- elec88$neig # neig(area = fr.area)
+
+     # 4
+     fr.poly <- area2poly(fr.area)
+     fr.nb <- neig2nb(fr.neig)
+     maptools:::plot.polylist(fr.poly, attr(fr.poly, "region.rect"), border = "grey")
+     plot(fr.nb, fr.xy, add = TRUE)
+     s.label(fr.xy, clab = 0, area = fr.area, neig = fr.neig,
+     cneig = 1, cpo = 2, inc = FALSE, addax = FALSE)
+ par(mfrow=c(1,1))
+ }
deldir 0.0-12

     Please note: The process for determining duplicated points
     has changed from that used in version 0.0-9 (and previously).

>
>
> data(irishdata)
> w <- irishdata$area[c(42:53,18:25),]
> w
   poly   x  y
42  S07  16 50
43  S07  16 44
44  S07  44 47
45  S07  21 34
46  S07  20 20
47  S07  28 19
48  S07  46 23
49  S07  30  8
50  S07  45 12
51  S07  68 35
52  S07  68 59
53  S07  63 78
18  S04  68 35
19  S04  68 59
20  S04 112 55
21  S04 119 50
22  S04 132 25
23  S04  74  0
24  S04  45  0
25  S04  45 12
> w$poly <- as.factor(as.character(w$poly))
> area.plot(w, clab = 2)
>
> points(68, 59, pch = 20, col = "red", cex = 3)
> points(68, 35, pch = 20, col = "red", cex = 3)
> points(45, 12, pch = 20, col = "red", cex = 3)
> sqrt((59-35)^2)+sqrt((68-45)^2+(35-12)^2)
[1] 56.52691
> area2link(w)
         S07      S04
S07  0.00000 56.52691
S04 56.52691  0.00000
>
>
>
>
